Vertical Villa Porch Lift is a cost-effective home accessibility solution to give scooter and wheelchair users an alternative to entryway or deck steps. It designs to provide cost-effective access into or within private homes or public buildings. The porch elevator is an unenclosed vertical platform lift that can be installed directly on the floor or in a pit (check local codes – pit mounted open vertical lifts are not permissible everywhere). This durable and easy-to-use vertical platform lift is suitable for indoor or outdoor applications requiring vertical transportation up to five feet.
Wheelchair lift is vertical lift platform for disabled people, suitable for indoor or outdoor, provides safe and convenient access in different level, includes access solutions for churches, schools or commercial sites etc. It is customized design for your real condition to install a convenient lift.
Customized Production
Lift height: 1m – 12m
Load capacity: 250kg – 350kg
Platform size: 1000*1200mm
Installation: In a pit or directly on the ground, mobile lift with wheels is also OK.
Model | Platform Size | Load Capacity | Lifting Height | Dimension | Machine Weight | |
7LSJW0.3-1 | 1.2x1m (can be designed, bigger or small) | 300kg (Max 500kg loading ) | 1m | 1.3×1.4×2.1m | 560kg | |
7LSJW0.3-2 | 2m | 1.3×1.4×3.1m | 850kg | |||
7LSJW0.3-3 | 3m | 1.3×1.4×4.1m | 900kg | |||
7LSJW0.3-4 | 4m | 1.3×1.4×5.1m | 960kg | |||
7LSJW0.3-5 | 5m | 1.3×1.4×6.1m | 1000kg | |||
7LSJW0.3-6 | 6m | 1.3×1.4×7.1m | 1100kg | |||
Lifting height below 2m also can be movable type, it is widely used in stage lifting. | ||||||
Drive System | Hydraulic | |||||
Min Platform height | 65mm | |||||
Configuration | Open through or front and side entrances | |||||
Speed | 4-6m/m | |||||
Power Input | 220V/50HZ/1PH/2.2KW | |||||
Emergency Stop | The lift can be stopped immediately in case of any emergency | |||||
Emergency Lowering | The lift can be lowered by manual down button in case of power failure | |||||
