Cargo lift is also known as goods lift, freight elevator, or mezzanine lift. Hydraulic goods lift provides fast, efficient, convenient and safe access to mezzanines, basement, garage and any level in multistoried buildings, suit numerous requirements and applications, such as places where pits cannot be excavated, and narrow spaces where the top level cannot reach.
These Warehouse Cargo Lift elevating platforms are fully customized to fit your needs. Available as electric hydraulic powered systems, scissor type and guide rail H type are available as well. SevenLift professional engineer teams will discuss and design ideal warehouse cargo lift according to client’s requirements.
Stationary scissor cargo lift is widely used in lifting operations over large areas, such narrow space as warehouses, factories, highways and stairwell place where we could not dig pits as well. It is customized design for your real condition to install a convenient lift.
Custome Information:
Lift height: detail from 1m – 10m
Load capacity: 100kg – 30000kg
Platform size: as your request
Installation: In a pit.
Covered color is optional
Technical parameter:
Model | Platform Size | Load Capacity | Lifting Height | Dimension | Motor Power |
7LSJG2-1.2 | 1.2×1.1m | 2000kg | 1.2m | 1.2×1.1×0.55m | 380v,3kw,3 phase |
7LSJG0.3-2 | 1×0.6m | 300kg | 2m | 1×0.6×0.5m | 220v,2.2kw,1 phase |
7LSJG0.6-3 | 2x1m | 600kg | 3m | 2x1x0.65m | 220v,2.2kw,1 phase |
7LSJG4-4 | 3.5×2.5m | 4000kg | 4m | 3.5×2.5×0.9m | 380v,5.5kw,3 phase |
7LSJG3-9 | 5.5×2.5m | 3000kg | 9m | 5.5×2.5×1.35m | 380v,5.5kw,3 phase |
Drive System | Hydraulic | ||||
Speed | 4-6m/m | ||||
Emergency Stop | The lift can be stopped immediately in case of any emergency | ||||
Emergency Lowering | The lift can be lowered by manual down button in case of power failure | ||||
Safety device | Safety sensors on the bottom of the platform | ||||
